6KW Vehicles Battery Cooling Thermal Management System
Trucks, Buses, Engineering Machinery Vehicles, etc.
-30-45°C
• Integrated design to reduce on-site installation and commissioning costs.
• High-efficiency variable frequency compressor with variable frequency design for superior energy efficiency.
• Stepless speed regulation of the compressor for intelligent cooling capacity adjustment.
• Intelligent fan speed regulation to match real-time thermal loads, achieving energy savings and noise reduction.
• Equipped with a CAN communication interface for BMS monitoring via CAN protocol.
• High reliability, capable of 24/7 operation, 365 days a year.
• Specifically designed for engineering vehicles with reinforced metal casing for enhanced vibration resistance.
• Incorporates electromagnetic interference (EMI) design, suitable for most harsh working conditions.
• Electrical controls feature IP67 protection for high safety standards.
• Uses automotive-grade compressors and electronic control chips, meeting vehicle application requirements.
Type | Parameter |
|---|---|
Operating Ambient Temperature | -30-45°C |
AverageInput Electric Power(kW) | ≯3kw(Including Accessory Losses) |
Comprehensive Energy Efficiency Ratio(COP) | ≮2.0(Rated Conditions) |
High Voltage Power input Range | DC180-470V |
Low Voltage Operating Voltage Range | 16-32VDC |
High Voltage Power | 3kw |
Low Voltage Power | 500W+120W(Fan + Pump) |
Unit Dimensions | 360*462*380mm |
Inlet Water Port Size | 25mm |
Outlet Water Port Size | 25mm |
Control Method | CAN2.0 |
