8KW Vehicle Battery Cooling Thermal Management System
Trucks, Buses, Engineering Machinery Vehicles, etc.
5-50°C
• Integrated design to reduce on-site installation and commissioning costs.
• High-efficiency variable frequency compressor with variable frequency design for superior energy efficiency.
• Stepless speed regulation of the compressor for intelligent cooling capacity adjustment.
• Intelligent fan speed regulation to match real-time thermal loads, achieving energy savings and noise reduction.
• Equipped with a CAN communication interface for BMS monitoring via CAN protocol.
• High reliability, capable of 24/7 operation, 365 days a year.
• Specifically designed for engineering vehicles with reinforced metal casing for enhanced vibration resistance.
• Incorporates electromagnetic interference (EMI) design, suitable for most harsh working conditions.
• Electrical controls feature IP67 protection for high safety standards.
• Uses automotive-grade compressors and electronic control chips, meeting vehicle application requirements.
Type | Parameter |
|---|---|
Operating Ambient Temperature | 5-50°C |
AverageInput Electric Power(kW) | ≮8kw(Including Accessory Losses) |
Comprehensive Energy Efficiency Ratio(COP) | ≮2.0(Rated Conditions) |
High Voltage Power input Range | DC450-790V |
Low Voltage Operating Voltage Range | 18-32VDC |
High Voltage Power | 5kw |
Rated Cooling Capacity(L35°C/W18°C)(kW) | 8(BMS 5KW+HVAC 3KW) |
Unit Dimensions | 910*578*317mm |
Inlet Water Port Size | 25mm |
Outlet Water Port Size | 25mm |
Control Method | CAN2.0 |
